FURUNO FELCOM 16 Inmarsat Mini-C
FURUNO Electric Co., Ltd.
Refurbished
Original SM MARINE SERVICE™ product photograph of a FURUNO FELCOM 16 communication equipment arrangement, including the main communication unit, antenna and associated accessories. Individual accessory model numbers must be checked against their labels.
|
Specification |
Details |
|---|---|
|
Manufacturer |
FURUNO Electric Co., Ltd. |
|
Manufacturer Location |
Nishinomiya, Japan |
|
Main Product |
FELCOM 16 |
|
Equipment Type |
Inmarsat Mini-C Mobile Earth Station |
|
Communication Class |
Class 2 |
|
Communication Unit |
IC-216 |
|
Antenna Unit |
IC-116 |
|
FELCOM 16 SSAS Junction Box |
IC-315 |
|
SSAS Alert Unit |
IC-307 |
|
Built-in Position Source |
GPS receiver |
|
Main Services |
Mini-C messaging, EGC, SSAS and LRIT-capable reporting |
|
Main Power Supply |
12–24 V DC, according to published model specifications |
|
Manufacturing Country |
Japan, as marked on the IC-216 nameplate |
|
Compass Safe Distance, IC-216 |
Standard 0.3 m / Steering 0.3 m |
|
Equipment Condition |
To be confirmed individually |
|
Availability |
Complete-set and individual-part enquiries |
|
International Shipping |
Available subject to confirmation |
The FURUNO FELCOM 16 Inmarsat Mini-C Mobile Earth Station is marine satellite communication equipment used for ship-to-shore messaging, ship security alerting and position reporting.
The system is built around the IC-216 communication unit and IC-116 antenna, with additional equipment such as the IC-315 junction box and IC-307 SSAS alert buttons in applicable ship security installations.
The FELCOM 16 is designed to operate with a connected computer and appropriate communication software. The system incorporates a GPS receiver to provide ship position information for supported reporting functions.
FURUNO developed the FELCOM 16 as a compact Mini-C system capable of Enhanced Group Call (EGC) reception, message handling, data reporting and polling. The SSAS configuration supports transmission of security alerts to designated shore recipients.
For shipowners, technical superintendents, radio technicians and marine purchasing departments, accurate identification of the IC-series components is essential when replacing defective equipment.
SM MARINE SERVICE™ supports international enquiries for complete FELCOM 16 arrangements, communication units, antennas, SSAS components, junction boxes and associated marine communication spare parts.
Website: www.smmarineservice.com
Original photograph showing the FELCOM 16 communication unit IC-216 identification label, Class 2 designation, compass safe distance and manufacturer details.
The visible label identifies the equipment as an INMARSAT MINI-C MOBILE EARTH STATION, model FELCOM 16, communication unit Class 2, type IC-216.
The serial label begins with 3534-; its trailing digits should be rechecked from the physical label rather than relying solely on the photograph. The unit carries a CE 0560 marking and FURUNO Electric Co., Ltd. manufacturer identification.
FELCOM 16 is a compact Inmarsat Mini-C communication system designed for compatible maritime satellite communication services.
It provides two-way store-and-forward messaging, including supported text and data services, and can receive EGC broadcasts such as SafetyNET and FleetNET messages.
In an SSAS installation, the system can transmit a security alert with vessel-identification and position information to preconfigured recipients without displaying the conventional audible or visual alarm associated with a distress alert.
For LRIT, the FELCOM 16 can provide position reporting when appropriately configured and accepted by the relevant service and administration.
Important: SSAS and LRIT functionality does not automatically mean that every FELCOM 16 installation is approved as a complete GMDSS distress terminal. The approved application, configuration and current service support must be verified for the vessel.
Class 2 Inmarsat Mini-C mobile earth station.
Compact IC-116 antenna arrangement.
IC-216 communication unit with integrated GPS receiver.
Two-way store-and-forward messaging.
EGC reception for supported maritime information services.
Position reporting and polling.
Ship Security Alert System support.
LRIT-capable reporting.
PC-based operation through appropriate software.
Compatible cable and accessory connections according to the system configuration.
The exact available functions depend on the installed software, service registration and equipment configuration.
|
Parameter |
FURUNO FELCOM 16 |
|---|---|
|
Satellite Service |
Inmarsat Mini-C |
|
Class |
Class 2 |
|
Communication Unit |
IC-216 |
|
Antenna |
IC-116 |
|
GPS |
Internal receiver |
|
Transmit Frequency |
1626.5–1646.5 MHz |
|
Receive Frequency |
1530.0–1545.0 MHz |
|
GPS Frequency |
1575.42 MHz |
|
Channel Spacing |
5 kHz |
|
Modulation |
BPSK, 1200 symbols/s |
|
Power Supply |
12–24 V DC |
|
Published Consumption |
Approximately 60 W transmitting / 10 W receiving |
|
Antenna Protection |
IPX6, according to manufacturer specifications |
|
Communication Unit Weight |
Approximately 1.2 kg |
|
Antenna Unit Weight |
Approximately 1.4 kg |
|
Typical Antenna Cable |
30 m in published SSAS configuration |
|
Optional Supply Equipment |
PR-240 AC/DC power supply |
The figures represent published FELCOM 16 specifications and should not be confused with measurements from the photographed used equipment.
Close-up of the original FURUNO FELCOM 16 IC-216 communication unit label, useful for exact model identification when ordering a replacement.
The IC-216 Communication Unit is the main electronics assembly in the FELCOM 16 system. It performs the communications functions and incorporates an internal GPS receiver.
For replacement enquiries, buyers should verify the IC-216 type label, system configuration, cable connections and service-related requirements.
The IC-116 Antenna Unit provides the satellite radio interface for the FELCOM 16.
It is designed for an exposed marine installation and must be correctly positioned and connected using suitable antenna cable.
The IC-116 is a specific equipment model. Antennas from other FELCOM generations should not be regarded as interchangeable without manufacturer confirmation.
The IC-315 Junction Box is documented as the junction box used in the FELCOM 16 SSAS arrangement. It connects relevant security-alert circuits to the communication system.
The model number on the separate junction box pictured in the supplied equipment photograph is not conclusively identifiable as IC-315. Therefore, the actual accessory label must be verified before listing that pictured component as an IC-315.
Original photograph detail of an associated junction box. Confirm its exact type number from the physical identification label.
The IC-307 SSAS Alert Unit is a dedicated ship security alert activation device.
In the FELCOM 16 SSAS configuration, FURUNO documentation specifies two alert units as standard, with up to three connectable.
The IC-307 must be installed and tested in accordance with the vessel's approved ship security arrangements. Testing should be coordinated with authorized personnel to prevent unintended alerts.
|
Model |
Component |
Association |
|---|---|---|
|
IC-305 |
Distress Alert / Received Call Unit |
Associated FELCOM 15 equipment |
|
IC-306 |
Alarm Unit |
Associated FELCOM 15 equipment |
|
IC-315 |
Junction Box |
FELCOM 15 / 16 SSAS arrangements |
|
IC-318 |
Junction Box |
Related FELCOM 18 / 19 equipment |
|
IC-118 |
Antenna Unit |
FELCOM 18 |
|
IC-119 |
Antenna Unit |
FELCOM 19 |
|
IC-218 |
Terminal Unit |
FELCOM 18 |
|
IC-219 |
Communication Unit |
FELCOM 19 |
|
PR-240 |
AC/DC Power Supply |
Applicable FURUNO satellite communication installations |
These related model numbers are provided to help buyers identify equipment families. They do not establish direct interchangeability.
The FELCOM 16 is relevant to marine satellite communication and ship security arrangements aboard compatible merchant vessels, tankers, bulk carriers, container ships and other commercial ships.
Its applications include:
Ship Security Alert System (SSAS).
Long-Range Identification and Tracking (LRIT).
Satellite position reporting.
Maritime data messaging.
EGC maritime information reception.
Shore-to-ship and ship-to-shore messaging where supported.
Replacement and maintenance of existing FURUNO Mini-C installations.
Current service availability and compliance must be confirmed with the responsible service provider, flag administration and relevant survey requirements.
The following symptoms and checks are relevant to FELCOM 16 maintenance.
|
Problem |
Possible Cause |
Recommended Check |
|---|---|---|
|
Communication unit does not power on |
Supply or internal power fault |
Check the approved supply, protection and connections |
|
Cannot establish satellite communication |
Antenna, RF cable or registration issue |
Inspect the antenna system and service status |
|
Synchronization loss |
Satellite acquisition or receiving problem |
Check the selected region, antenna and signal conditions |
|
High BBER indication |
Poor received signal or interference |
Inspect the antenna, cable and signal status |
|
GPS position unavailable |
GPS receiver or reception issue |
Check the reported GPS status and applicable diagnostics |
|
SSAS test unsuccessful |
Alert circuit, settings or service issue |
Use the authorized SSAS test procedure |
|
No PC communication |
Interface cable, software or port configuration |
Verify the PC connection and approved settings |
|
LRIT reporting failure |
Service, configuration or communication issue |
Follow the approved LRIT troubleshooting process |
FELCOM 16 operating documentation describes warning messages involving internal GPS failure, synchronization loss and excessive BBER, among other conditions.
For example, an internal GPS failure warning indicates that valid position information is not being obtained from the internal receiver. A synchronization-loss warning requires investigation of the communications status and operating region.
These indications should be interpreted using the applicable software version and diagnostic procedures. A warning is not proof that a particular PCB has failed.
Record the IC-216 identification and displayed status.
Verify the power supply and permitted operating conditions.
Inspect the antenna and cable system through qualified personnel.
Check satellite registration, synchronization and GPS information.
Inspect the appropriate interface connections.
Review the specific warning and approved troubleshooting procedure.
Arrange specialist repair or configuration checks where required.
Never trigger a live SSAS alert for an informal test. Security-alert testing must follow the ship security plan and the approved service procedures.
Regular maintenance of a marine satellite communication system should include visual inspection of the antenna, mounting and exposed cable connections.
The communication unit should be inspected for corrosion, moisture exposure and physical damage. All accessible connectors must be secured in accordance with the installation procedures.
Personnel should also verify approved GPS reception, communication status and required reporting functions.
Maintain records of equipment identifiers, service configuration, inspection results and replacement components.
Because FELCOM 16 may be associated with vessel security and tracking functions, changes to operating parameters should be controlled and documented.
SM MARINE SERVICE™ supports enquiries for the FURUNO FELCOM 16 Inmarsat Mini-C system and associated marine satellite communication equipment.
The supplied stock information identifies a complete FELCOM 16 arrangement and separate associated components available for enquiry, including the communication unit, antenna, junction-box equipment, alert-button units and cables.
Potential sourcing requirements include:
Complete FURUNO FELCOM 16 system.
IC-216 Communication Unit.
IC-116 Antenna Unit.
IC-315 Junction Box, subject to exact part identification.
IC-307 SSAS Alert Unit.
Compatible interface and antenna cables.
Applicable power supply equipment.
Other verified FELCOM-series spare parts.
Availability and condition should be confirmed for each specific component. SM MARINE SERVICE™ can also support enquiries for new, used, refurbished, reconditioned or tested-working alternatives, depending on sourcing availability.
Please provide the exact FELCOM model, required IC-series component, equipment nameplate photograph, existing system configuration and quantity required.
For complete system replacements, confirm the destination vessel's approved application, registration requirements, interfaces and compatibility before commissioning.
International buyers can request pricing and worldwide shipping information through www.smmarineservice.com.
Vessels fitted with FELCOM 16 installations may require compatible replacement communication units, antennas and interface components to maintain the existing satellite communication arrangement.
Replacing an individual identified component can sometimes avoid extensive modification to the ship's existing wiring and equipment layout.
However, because satellite communication services and regulatory acceptance can change, the suitability of a legacy installation must be checked before purchase or reinstallation. A physically compatible replacement does not automatically establish approved SSAS, LRIT or GMDSS operation.
It is a Class 2 Inmarsat Mini-C Mobile Earth Station intended for compatible maritime satellite communication, messaging and reporting functions.
IC-216 is the main communication unit used in the FELCOM 16 system. It contains an internal GPS receiver.
The documented FELCOM 16 antenna is the FURUNO IC-116.
It is a junction box used in applicable FELCOM 15 and FELCOM 16 SSAS arrangements.
It is a Ship Security Alert System activation unit used in compatible FURUNO SSAS installations.
FELCOM 16 documentation describes LRIT-compatible position reporting. Actual operation depends on approval, registration, configuration and service availability.
Yes. The published system specifications include EGC receiving functionality.
Potential causes include signal reception problems, antenna-system faults or incorrect communications status. The approved diagnostic procedure should be followed.
Do not assume direct interchangeability. The models use different principal unit numbers, and complete compatibility must be verified.
Contact SM MARINE SERVICE™ to enquire about IC-216, IC-116, SSAS components and related marine satellite communication spare parts.
SM MARINE SERVICE™ accepts enquiries for different equipment conditions. The exact condition, inspection status and availability must be confirmed before ordering.
International buyers can request worldwide sourcing and shipping arrangements, subject to stock availability and destination requirements.
The FURUNO FELCOM 16 Inmarsat Mini-C Mobile Earth Station is a marine satellite communication system incorporating the IC-216 Communication Unit and IC-116 Antenna Unit. Compatible SSAS installations may include the IC-315 Junction Box and IC-307 Alert Units. The system supports maritime messaging, EGC reception and appropriately configured SSAS and LRIT functions. SM MARINE SERVICE™ supports worldwide enquiries for complete FELCOM 16 equipment, communication units, antenna assemblies, alert components, cables and compatible marine communication spare parts. Buyers should confirm the exact IC-series model, equipment condition, interfaces, service requirements and regulatory suitability before ordering.
